Base Part Number: 330180-X2-00

Modification Code: 181634-27

Manufacturer: Bently Nevada (a Baker Hughes business)

Product Category: Vibration Monitoring System Components

The Bently 330180-X2-00 (modified per 181634-27) is a proximity probe extension cable assembly, a critical part of Bently Nevada’s 3300 series vibration monitoring system. It connects proximity probes to signal conditioners, transmitting accurate vibration, position, and speed data while maintaining signal integrity in industrial environments.

Key Specifications & Modification Notes

• Designed for compatibility with Bently 3300 series proximity probes and 3300/3500 signal conditioners
• Modification 181634-27 typically includes tailored cable length, connector type, or insulation material for specific application needs
• Constructed with industrial-grade materials to resist moisture, temperature fluctuations, and electromagnetic interference (EMI)
• Ensures stable signal transmission for precise machinery health monitoring

Typical Applications

Widely used in power generation, oil and gas, petrochemical, and heavy manufacturing industries. It supports vibration monitoring for turbines, compressors, motors, and other rotating machinery, enabling predictive maintenance and preventing unplanned downtime.

Part Number: MVI56E-61850C

Manufacturer: ProSoft Technology

Product Series: MVI56E Communication Modules

Functional Description

The MVI56E-61850C is a communication module designed to enable seamless integration between Rockwell Automation ControlLogix systems and IEC 61850-compliant devices. It acts as a gateway, facilitating data exchange using the IEC 61850 standard, which is widely adopted in power system automation.

Key Capabilities

• Supports IEC 61850-8-1 (MMS) and GOOSE (Generic Object Oriented Substation Event) protocols
• Provides bi-directional data transfer between ControlLogix and IEC 61850 devices
• Configurable data mapping for flexible integration with substation automation systems
• Redundant operation support for enhanced system reliability
• Compatible with ControlLogix 5570 and newer controllers

Application Scenarios

Ideal for power utilities, substations, and electrical distribution systems where integration between Rockwell Automation control systems and IEC 61850-based intelligent electronic devices (IEDs) is required. It enables real-time monitoring, control, and data logging in critical power infrastructure.

The GE IS200TRTDH1CCC is a RTD (Resistance Temperature Detector) input module designed to interface with temperature sensors in industrial control systems. It processes analog signals from RTDs, converting them into digital data for monitoring and control purposes within the Mark VIe system architecture.

Related series:

GE IS200TSVOH1BDC

GE IS200TPROH1BCB

GE IS200TTURH1BED

GE IS200VTCCH1CBD

GE IS200VRTDH1DAC

GE IS200VCRCH1BBC

GE IS200VVIBH1CAC

GE IS200VAICH1DAB

GE IS202RKPSG2A

GE IS200VSVOH1BEF

Technical Characteristics

• Supports multiple RTD types (e.g., Pt100, Pt1000) for versatile temperature measurement
• High-precision signal conditioning for accurate temperature readings
• Integrated diagnostics for fault detection and system reliability
• Designed for harsh industrial environments with robust EMI/RFI protection
• Compatible with Mark VIe controller platforms and I/O networks

Typical Applications

Commonly deployed in power generation, petrochemical, and heavy manufacturing industries. It is used to monitor critical temperature parameters in turbines, generators, and other industrial machinery, enabling precise control and preventive maintenance.

Product Code: IS200TBTCH1CBB

Manufacturer: General Electric (GE)

Category: Industrial Control System Component

General Description

The IS200TBTCH1CBB is a key component in GE’s Mark VIe control system, designed for turbine and machinery control applications. It serves as a terminal board, facilitating secure and reliable electrical connections within the control system architecture.

Key Features

• Compatible with Mark VIe control system platforms
• Robust design for industrial environments
• Facilitates organized wiring and connection management
• Compliant with relevant industry standards for reliability

Application Scope

Primarily used in power generation, oil and gas, and other heavy industries where precise turbine and machinery control is critical. It integrates with other Mark VIe components to ensure seamless system operation.

1. Product Identity & Purpose

• Model Code: IS215VCMIH2CC
• Manufacturer: General Electric (GE) Power & Water
• Product Category: Voltage Control Module (VCM) for GE Mark VIe Distributed Control System (DCS)
• Core Function: Manages, monitors, and regulates voltage signals in critical industrial assets (gas turbines, steam turbines, generators) to ensure stable operation

• Analog Inputs: 8 channels (0-10V DC), 16-bit resolution, optically isolated
• Analog Outputs: 4 channels (0-10V DC), 12-bit resolution, short-circuit protected
• Digital I/O: 6 digital inputs (24V DC) / 4 digital outputs (relay, 5A @ 250V AC)
• Power Supply: 24V DC ±10% (draws max 1.2A from Mark VIe system bus)
• Isolation Rating: 2.5kVrms (signal to ground), 1kVrms (power to signal)

3. System Integration & Features

• Communicates via GE Speedtronic® backplane for seamless data exchange with Mark VIe controller
• Configurable via GE ToolboxST software (supports custom voltage control loops, alarm logic)
• Built-in diagnostics: open-circuit detection, over-voltage monitoring, and module health status
• LED status indicators: Power (green), Communication (blue), Fault (red), I/O Activity (amber)

4. Environmental & Mechanical Data
