ABB AO810 | 3BSE008522R1 | Analog Output Module

Operating Voltage:DC 24V

Current Output Range:0 to 20mA

Supply Current:Max. 60mA

Temperature Range:-25°C to +60°C

Relay Contacts:2 x SPDT

Load Capacity:250VAC / 30VDC, Max. 5A

Communication Interface:Built-in Modbus RTU

Dimensions:90mm x 90mm x 44mm

Weight:Approx. 0.2kg

    The ABB AO810 3BSE008522R1 is engineered to deliver exceptional performance in industrial control applications. Its compact design and robust build quality make it suitable for integration into diverse automation systems. This module supports a wide range of analog outputs, enabling precise control over motors, valves, and other actuators.

    Equipped with a Modbus RTU interface, the AO810 3BSE008522R1 facilitates seamless communication with other devices in the network, ensuring efficient data exchange and system coordination.

    With an operating voltage range of 12-24V DC, this module ensures compatibility across various power supplies found in industrial environments. Its adjustable current output of 0-20mA or 4-20mA allows for fine-tuning to meet specific application requirements, enhancing control accuracy and response time.

    Featuring a power rating of up to 25W, the AO810 3BSE008522R1 can handle substantial loads, making it ideal for applications requiring high output power. Its compact size and lightweight design facilitate easy installation and integration, reducing the overall system footprint.

    Designed for durability and long-term reliability, the ABB AO810 3BSE008522R1 is built to withstand harsh industrial conditions. Its advanced manufacturing techniques ensure consistent performance even under extreme temperatures and environmental stresses, providing a dependable solution for continuous operation.
