Operating Voltage:800 Volts DC
Internal Shunt Resistance:20 Ohms
Dimensions:9.54 x 15.43 x 8.0 inches (242.2 x 391.8 x 203.2 mm)
Continuous Output Current:47A
Intermittent Output Current:94A
Continuous Power Output:10.0 kW @ 480 VAC, 5.0 kW @ 230 VAC
Operating Temperature Range:0°C to 55°C
Relative Humidity Range:0% to 95% non-condensing
USB Support:USB 1.0 and 2.0 (communication rates up to 38,400 bps)
The Allen-Bradley 2098-DSD-HV220-SE is a cutting-edge high-voltage AC drive that delivers unmatched performance in industrial settings. Its robust design ensures durability and reliability under extreme conditions.
Featuring advanced indexing capabilities and precise variable PID control, this drive optimizes velocity and positioning accuracy, making it ideal for complex automation tasks. The PWM frequency input enhances its responsiveness and efficiency.
With a wide range of power outputs at both 230 Vac and 480 Vac, the 2098-DSD-HV220-SE accommodates diverse machinery needs, providing both efficiency and flexibility in energy management.
Equipped with a DC shunt resistance of 20 Ohms and capable of handling shunt voltage when powered on, the drive ensures stable operation even in fluctuating voltage scenarios. Its internal shunt resistance contributes to better current regulation and control.
The drive’s compact size, measuring 9.54 x 15.43 x 8.0 inches, allows for easy installation in tight spaces without compromising performance. Additionally, its operating temperature range of 0 to 55 °C and non-condensing relative humidity up to 95% ensure reliable operation in various industrial environments.
Certified for compliance with various drive standards and meeting all EMC directives, the Allen-Bradley 2098-DSD-HV220-SE ensures seamless integration into existing systems while maintaining high levels of safety and interference protection.
