Allen-Bradley SLC500 1746-NIO4V/A High-Resolution Analog I/O Module

Model Type:SLC500

Model Number:1746-NIO4V/A

Manufacturer:Allen Bradley

Module Type:Analog Combination Module

Resolution:High Resolution

Number of Input Channels:2

Number of Output Channels:2

Common Mode Voltage Range (Input):-20 to 20 V

Absolute Input Voltage (Max.):±7.5 VDC or ±7.5 VAC RMS

Input Range (Current):-20 to 20 mA

Absolute Input Current (Max.):-30 to 30 mA

Output Range (Voltage):-10 to 10 V – 1 LSB

Full Scale Output Voltage:10 VDC

Overvoltage Protection (Voltage):7.5 VAC RMS

Output Range (Voltage Control):-10 to 10 VDC – 1 LSB

    The Allen Bradley 1746-NIO4V/A is an essential component for any industrial automation system requiring high precision analog inputs and outputs.

     This module features two input channels and two output channels, providing a versatile solution for a wide range of industrial applications.

     With its high resolution and accurate voltage and current handling capabilities, this module ensures reliable and consistent performance under demanding conditions.

     The Allen Bradley brand is renowned for quality and durability, making this module a trusted choice for professionals in the field.
