AMCI HT-20 Single-Turn Resolver Transducer – High Precision Motion Control

Operating Range:±90°

Accuracy:±0.05°

Resolution:0.01°

Supply Voltage:DC 12V – 36V

Output Signal:0-10V DC or 4-20mA

Environmental Conditions:-40°C to +85°C

Enclosure Type:IP65 Waterproof

Mounting:Panel Mount

    The AMCI HT-20 Single-Turn Resolver Transducer boasts an exceptional resolution of 0.001 degrees, ensuring precise angular position measurement even in the most challenging environments.

    Featuring a remarkable accuracy of +/- 0.02% of reading or +/- 0.02 degrees, this sensor delivers unparalleled reliability and consistency.

    Operable within an extensive temperature range from -40°C to +105°C (-40°F to +221°F), it withstands extreme conditions without compromising performance.

    With its versatile input voltage of DC 12V to 28V, the HT-20 is compatible with a wide array of power sources, making it adaptable to various industrial setups.

    Equipped with a 10-bit digital output signal, the transducer ensures accurate data transmission, crucial for real-time monitoring and control systems.

    The M12 connector design with a 7-pin mating connector facilitates easy installation and maintenance, enhancing operational efficiency.

    Protected by an IP65 enclosure type, this sensor is dustproof and splash-proof, ideal for outdoor or dusty industrial environments.

    Constructed with a stainless steel housing and epoxy sealing, the HT-20 is built to endure harsh conditions, offering a long service life with minimal maintenance requirements.
