Number of pins:12
Type of terminal block:Push-in terminal
Cable type:Only copper wires (no aluminum wires!)
Wire stripping length:7 to 9 mm
Nominal voltage:240 VAC
Max. voltage:300 VAC
The B&R X20TB12 Extended Automation Module is designed for ease and efficiency in industrial automation environments. It supports tool-free wiring through its innovative push-in technology, allowing for quick and secure connections without the need for additional tools. The ability to simply release wires using a lever ensures a clean and quick disconnection process, enhancing maintenance and troubleshooting operations.
Each terminal can be conveniently labeled, making it easier to identify and manage different circuit paths within complex systems. This feature is particularly beneficial in large-scale industrial settings where precise labeling is crucial for operational safety and system reliability.
The module’s compatibility with plain text labeling provides flexibility in marking terminals, facilitating the use of common labels or custom codes. This ensures clear identification even when dealing with a variety of languages or specific industry standards.
Additionally, the X20TB12 module allows for standard test probe access, which is essential for routine inspections and troubleshooting. This feature minimizes downtime and streamlines the diagnostic process, contributing to overall system uptime and efficiency.
Moreover, the inclusion of a special color coding for the 240 V AC rating enhances visual differentiation and safety. This prevents accidental overvoltage and ensures that users can quickly identify the power level of each connection, reducing the risk of electrical hazards in the workplace.
