Manufacturer:National Instruments
Model Number:NI-9505
Module Type:Analog Input Module
Input Channels:8 Channels
Resolution:16-bit
Sampling Rate:Up to 1 MHz per channel
Voltage Range:+/-10V
Accuracy:+/-0.05% FS
Isolation:Channel-to-earth isolation
Operating Temperature:-40°C to +85°C
Power Supply:5V DC
The NI-9505 Analog Input Module is designed to deliver reliable and accurate measurements in demanding industrial applications. Its advanced 16-bit resolution ensures high precision and low noise, making it ideal for a wide range of data acquisition tasks.
With eight channels, the NI-9505 can simultaneously measure multiple inputs, providing flexibility and efficiency in system design. Each channel supports a wide input range of +/-10V, accommodating a variety of sensor outputs.
Built with robust components, the module operates reliably over a broad temperature range from -40°C to +85°C, ensuring stable performance in harsh environments. Its compact size (120mm x 90mm x 35mm) makes it easy to integrate into existing control systems without taking up excessive space.
The module is powered by a 5V DC supply, simplifying integration with other components. Additionally, the NI-9505 features a high sampling rate of 1 MS/s, allowing for real-time data monitoring and analysis.
Designed with ease of use in mind, the NI-9505 comes with a user-friendly interface and comprehensive documentation, making setup and maintenance straightforward. Whether you’re working in manufacturing, energy, or any other industry requiring precise data acquisition, the NI-9505 delivers outstanding performance and reliability.
