NI PXI-5154 Data Acquisition Module

Brand:NI

Model:PXI-5154

Series:NI PXI-5154

Operating Voltage:24 VDC

Sampling Rate:20 MS/s

Resolution:14 bits

Channels:4 differential or 8 single-ended

Input Range:+/-10 V

Interface:PXI Express

Dimensions:133 mm x 100 mm x 25 mm

Weight:0.3 kg

    The NI PXI-5154 Data Acquisition Module is built to deliver top-tier performance for demanding applications.

     With a resolution of 14 bits and a sampling rate of up to 100 MS/s, it provides precise and reliable data capture.

     Its modular design allows for easy integration into existing PXI/PXI Express systems, offering flexibility and scalability.

     Designed with a robust memory capacity of 512 MSamples, the module can handle extensive data acquisition tasks without losing quality.

     The compatibility with a wide range of operating voltages ensures adaptability across different environments.

     Ideal for use in industrial automation, test and measurement systems, and scientific research, this module supports the development of advanced monitoring and analysis systems.
