Operating Voltage:24VDC
Sampling Rate:up to 1 MHz
Number of Channels:16
Resolution:12 bits
Analog Input Range:-10V to +10V
Digital I/O:8 channels
PCIe Interface:Supports PXI Express for enhanced performance
Power Consumption:≤ 3.5W
The NI PXI-6509 is an indispensable tool for engineers and researchers seeking precision and reliability in their data acquisition needs. Its compact form factor makes it ideal for integration into a variety of test benches and control systems.
With its high-speed sampling capabilities, this module ensures that you capture transient signals accurately and quickly, making it suitable for dynamic processes in industries such as aerospace, automotive, and electronics.
Featuring 16 differential analog inputs, the PXI-6509 supports a wide range of sensor types, enabling comprehensive monitoring and analysis of physical phenomena.
The inclusion of 8 digital I/O channels provides flexibility for controlling external devices or interfacing with other components in a system, enhancing its utility in complex setups.
Equipped with a PCIe interface, the PXI-6509 seamlessly integrates with modern computer systems, offering fast data transfer speeds and compatibility with a wide array of software tools for data analysis and visualization.
