I/O Size:0/120/240 – 16 bit integers
Communication Parameters:Baud Rate: 110 to 115K baud, Stop Bits: 1 or 2, Data size: 7 or 8 Bits, Parity: None, Even, Odd, RTS Timing delays: 0 to 65535 milliseconds
Floating Point Data Movement:Supported, including configurable support for Enron, Daniel® and other implementations
Operating Temperature:-40° F to 140° F (0° C to 60° C)
Storage Temperature:-40° F to 185° F (-40° C to 85° C)
Processor Compatibility:Compatible with Rockwell Automation SLC 5/02 M0/M1 capable processors or newer
Ethernet Configuration:IP address for easy configuration, backward-compatible with previous MVI56-MNETR versions
Single-Slot ControlLogix Backplane:Compatible
Ethernet Speed:10/100 Mbps auto crossover detection
Module Memory Mapping:User definable module data memory mapping of up to 5000, 16-bit registers
Network Configuration & Diagnostics:CIPconnect-enabled network configuration and diagnostics monitoring using ControlLogix 1756-ENxT and 1756-CNB modules
Pass-through Communication:EtherNet/IP pass-through communication
Optimized Remote Rack Implementations:Reduced I/O image size designed specifically to optimize remote rack implementations
Configuration Software:ProSoft Configuration Builder (PCB) software included
The PROSOFT MVI56E-MNETC Modbus TCP/IP Client/Server Communication Module offers unparalleled reliability and efficiency in industrial environments. Designed with state-of-the-art technology, it supports floating point data movement including configurable support for Enron, Daniel, and other implementations. With its backward-compatible design, this module seamlessly integrates into existing systems, enhancing compatibility and reducing upgrade costs. Its compact and robust construction ensures long-lasting performance under harsh industrial conditions. Installation is straightforward, thanks to the user-friendly setup process, which includes IP address for easy configuration. Moreover, the module’s advanced diagnostics capabilities allow for real-time monitoring and troubleshooting, minimizing downtime and maximizing productivity. Whether you’re implementing a new system or upgrading an existing one, the PROSOFT MVI56E-MNETC is the ideal choice for reliable communication in industrial settings.
