Schneider TSXAEZ801 – 8-Channel 0-10 V Analog Input Module

Number of Channels:8

Analog Input Range:0-10 V

Conversion Resolution:12 bits

Current Consumption:60 mA

Weight:0.44 lb (US) / 0.2 kg

Connector Type:Sub-D 25

Operating Voltage:125 V DC

Power Dissipation:1 W + (0.62 x number of points)

    Experience unparalleled precision and reliability with the Schneider Electric TSXAEZ801, a 0-10 V analog input module designed for seamless integration into industrial control systems. This robust module is equipped with 8 high-precision channels, ensuring accurate data collection across various operational environments.

    Crafted with cutting-edge technology, the TSXAEZ801 boasts a 12-bit resolution for unparalleled accuracy, making it an ideal choice for applications requiring precise measurements. Its ±0.05% accuracy guarantees reliable performance, even under fluctuating conditions.

    Operable within an expansive temperature range of -20°C to +55°C, this module is built to withstand harsh industrial environments without compromising its functionality. The high input impedance ensures minimal interference from external sources, ensuring the integrity of the collected data.

    Equipped with a 24-pin DIN rail connection, the TSXAEZ801 is designed for easy installation and integration, simplifying setup processes for engineers and technicians. Its panel mounting design further enhances its flexibility and adaptability, catering to diverse installation requirements.

    Efficiency and durability are at the heart of the Schneider Electric TSXAEZ801. With a compact size measuring 80mm x 160mm x 92mm and weighing just 0.44 lbs (0.2 kg), it offers a compact solution without compromising on performance. This makes it an optimal choice for space-constrained industrial settings, enhancing operational efficiency and productivity.
