Model Number:JW-232S
Module Type:Transistor Output
Operating Voltage:DC 5V – 30V
Maximum Current:50mA per channel
Switching Speed:Less than 1ms
Operating Temperature Range:-20°C to +70°C
Operating Humidity Range:5% to 95% RH (non-condensing)
Dimensions (W x H x D):40mm x 20mm x 20mm
Weight:15g
Connector Type:Pin Header
Output Configuration:2 Channels
The SHARP JW-232S Transistor Output Module is a cutting-edge solution designed to meet the demanding requirements of industrial control systems. It boasts a robust design that ensures reliable operation under a wide range of environmental conditions, making it ideal for applications where precision and durability are critical.
Featuring a high-speed switching mechanism, this module allows for swift response times, crucial for systems requiring instantaneous control adjustments. Its ability to handle up to 1A resistive load per channel ensures compatibility with a variety of industrial equipment, enhancing its versatility.
With a power supply voltage of 24VDC and operating current of up to 50mA per channel, the JW-232S is capable of managing moderate electrical loads efficiently. Its 10μs switching speed ensures minimal signal delay, which is particularly beneficial in systems where rapid response is essential.
Equipped with an IP20 enclosure rating, the module offers basic protection against dust and splashing water, suitable for indoor industrial environments. Additionally, it supports 5V TTL/CMOS input logic levels, ensuring seamless integration with various control systems.
Offering two channels for dual output capability, the SHARP JW-232S is perfect for applications requiring parallel control over two different electrical loads. Its RS-232C communication interface facilitates easy connectivity with other system components, allowing for remote monitoring and control through standard serial protocols.
