ABB NINT-45C BSM25GD120DN2 – IGBT Module, for High-Power Electronics Applications

Power Rating:120kW

Operating Voltage:DC 250V

Frequency Range:0Hz to 6kHz

Switching Frequency:20kHz

Cooling Method:Air Cooled

Dimensions (LxWxH):250mm x 120mm x 45mm

Weight:2kg

Temperature Range:-20°C to +70°C

Input Current:160A

Output Current:320A

Insulation Class:F

Protection Level:IP20

    Engineered for unparalleled performance in high-power applications, the ABB NINT-45C BSM25GD120DN2 IGBT module is a cornerstone in modern industrial automation.

    Featuring advanced semiconductor technology, this module ensures efficient power conversion and minimizes energy loss, making it ideal for sectors requiring high reliability and low maintenance.

    With an operating temperature range from -40°C to +150°C, it is designed to withstand extreme environmental conditions without compromising performance or longevity.

    The use of Thermal Interface Material ensures optimal heat dissipation, enabling continuous operation under heavy load without overheating issues.

    Backed by ABB‘s commitment to quality, the NINT-45C BSM25GD120DN2 offers a failure rate significantly lower than industry standards, providing peace of mind for users in critical manufacturing processes.
