Brand:General Electric (GE)
Model:DS3800HRCA1C1B
Module Category:Signal Conditioning Process Board
Compatibility:For GE Speedtronic Mark IV Systems
Board Size:Standard Size
LEDs:Five (1 Yellow, 4 Red)
Jumpers:Two Sets with Removable Covers
Diodes:Multiple Diodes Present
Mounting Points:Five Mounting Points Provided
Connection Points:Nine Separate Connection Points for Wiring Harnesses
The DS3800HRCA1C1B board from General Electric is meticulously designed for seamless integration into the Speedtronic Mark IV turbine control systems. With its robust construction and reliable performance, this board plays a pivotal role in signal conditioning processes within industrial turbine controls. The board is equipped with five LED indicators—one yellow and four red—that visually indicate operational status, enhancing system monitoring capabilities. Featuring two sets of jumper ports, it allows for versatile configuration adjustments. Its black terminal plugin, conveniently located along one edge, facilitates easy connections. For secure installation, the board includes clips and two small screws for mounting. Additionally, it offers nine distinct connection points designed for compatibility with female harnesses, ensuring a robust and flexible setup.
